Matched Fasteners
Small Security Bits With Hex Shanks
13 security Torx bits covering T4-T40. Match the fastener, tool connection and available clearance before applying force.
Tamper Proof Torx Bit Set, Premium S2 Alloy Steel | 13-Piece Security Star Bits, T4 - T40 | Precision CNC Machined (LX-301)
Sale price
$11.97
Regular price
$13.97
Overview
LX-301 supplies 13 Torx bits on 1/4-inch hex shanks, covering T4 through the listed T40 sizes in a holder. T4 is solid; the other listed pieces use the security format. Choose it for matching small fasteners and a hex-bit driver, rather than a direct square-drive socket connection.
Key Advantages
Size Selection
Check The Included Sizes
T4 is explicitly not a security tamper-proof bit; the other listed sizes use the security format.
Materials
Steel Selected For The Tool
Heat-treated S2 alloy steel bits. Check the matching tool connection before use.
Work Limits
Use A Suitable Drive Tool
Rated for impact drivers, with a 1/4-inch hex connection. Match the bit to the fastener and the holder to the tool; the rating does not supply a per-size torque ceiling.
In The Box
Keep The Set Together
The package supplies 13 bits and a holder. Check every included size when unpacking. No ratchet or torque wrench is listed as included.
Will it fit the fastener?
Match the profile, exact size, tool connection and available clearance. A vehicle name alone does not establish fit.
| Fastener or tool | Fit | What to check |
|---|---|---|
| Matching security Torx fasteners | Yes, in the listed sizes | Check the full size inventory below and seat the correct profile completely. |
| Other fastener profiles | No verified fit | External E-Torx, hex, XZN and center-pin T4 require the matching tool. |
| Manual ratchets and torque tools | With matching connection | Use a compatible hex-bit holder. |
| Impact drivers | Yes, with a compatible holder | Use the matching 1/4-inch hex connection and fastener size; no numeric per-bit torque ceiling is established. |
| A vehicle make or model | Conditional | Check the actual fastener profile, size and clearance; a vehicle name is not a fit guarantee. |
| High-torque or confined work | Requires verification | No per-size torque limit or guaranteed access dimension is verified; check the service procedure. |
Tech Specs
- Model
- LX-301
- Fastener profile
- Security Torx
- Piece count
- 13
- Published size range
- T4-T40
- 1/4-inch hex shank sizes
- T4 (solid), T5, T6, T7, T8, T9, T10, T15, T20, T25, T27, T30, T40
- Bit material
- Heat-treated S2 alloy steel
- Storage
- Holder
- Country of origin
- Taiwan
- Package dimensions (L x W x H)
- 0.65 x 4.4 x 1.5 inches
- Package weight
- 0.13 lb
- Warranty
- Lifetime coverage when you register online within 90 days of purchase; 12 months standard without registration. Commercial: 12 months, no extension. Industrial: not covered.
- Powered-tool suitability
- Impact drivers; compatible 1/4-inch hex holder required
Questions
Can I use these for small Torx screws in electronics?
Yes, when the fastener uses an included Torx size from T4 to T40 and the bit can seat fully. T4 is solid; a center-pin T4 screw requires a different confirmed security bit. Use a matching 1/4-inch hex-bit holder.
Can I use the small security bits for a license-plate frame?
Use LX-301 when the license-plate frame screw requires one of its included security Torx sizes. Check the actual screw profile; T4 is solid and does not clear a center pin.
Which sizes connect to each drive tool?
1/4-inch hex shank: T4 (solid), T5, T6, T7, T8, T9, T10, T15, T20, T25, T27, T30, T40.
Does it fit security screws with a center pin?
T4 is solid and does not clear a center pin. Choose a different compatible security bit for a center-pin T4 screw; the other included sizes use the security format.
Will these bits attach directly to a 1/4-inch square-drive ratchet?
These 1/4-inch hex shanks require a matching bit holder. They do not attach directly to a 1/4-inch square-drive ratchet; use a suitable connection for hex bits.
Can a 1/4-inch hex screwdriver holder accept these shanks?
All thirteen LX-301 bits have 1/4-inch hex shanks for a matching hex-bit holder. That connection size does not mean each fastener recess is 1/4 inch across.
Can a torque handle using hex bits work with the small T6H piece?
Use a compatible 1/4-inch hex holder and a torque tool whose range suits the small fastener. Confirm a tool rating for T6H; its size and hex shank do not establish a safe torque ceiling.
Can I use these bits in a drill or driver?
Yes. LX-301 bits are rated for impact drivers. Use a compatible 1/4-inch hex-bit holder and the exact fastener size; the rating does not provide a numeric torque ceiling for every bit or guarantee safe use on delicate electronics.
Do these small bits have chrome vanadium socket bodies attached?
No socket bodies are listed. LX-301 is the set of heat-treated S2 bits with 1/4-inch hex shanks; the square-drive socket construction described for LX-146 is a different tool connection.
Are the often-needed T7 and T9 bits included?
Yes. T7 and T9 appear in the thirteen-size LX-301 inventory along with T4, T5, T6, T8, T10, T15, T20, T25, T27, T30 and T40. Select the exact small recess rather than stepping to the next larger bit.
Will these bits provide enough reach with an extension holder?
Choose a compatible 1/4-inch hex-bit holder and confirm the individual bit's working length for the actual electronics recess. An extension holder does not guarantee that the bit itself can seat fully.
Can I rely on these bits to hold a screw magnetically?
Do not rely on magnetic screw retention. The bits use 1/4-inch hex shanks; confirm a magnetism specification if retention is essential to your job.
How does LX-301 compare with LX-146?
LX-301 supplies 13 bits on 1/4-inch hex shanks from T4 to T40, with solid T4. LX-146 supplies 13 security bit sockets from T8H to T60H on square drives. Choose by the bit holder or ratchet connection and the exact fastener size.
Does the holder contain thirteen security-hole bits?
It holds thirteen listed Torx bits, but T4 is specifically not tamper-proof. The other listed sizes use the security format; a count of thirteen does not make the solid T4 suitable for a center-pin T4 screw.
Does this set have lifetime warranty coverage?
Lifetime coverage when you register online within 90 days of purchase; 12 months standard without registration. Commercial use has 12 months of coverage and cannot be extended; industrial use is not covered. Coverage is for defects in materials and workmanship, excluding normal wear, misuse, modification and non-original parts.
Which set should I choose for T60H rather than small hex-shank bits?
LX-301 ends at T40 and does not supply T60H. LX-146 lists a T60H security bit socket on a 1/2-inch square drive, which requires a different drive tool from LX-301's hex-bit holder.
Is a replacement T6H available through a documented ordering code?
Individual LX-301 bits are not sold separately. Lexivon can check the warehouse for a one-time spare; specify the exact T-size and security-hole format with the 1/4-inch hex shank, rather than assuming a T6 socket is the same component.
Does the 0.65-inch package dimension describe an individual bit?
No. 0.65 x 4.4 x 1.5 inches are package dimensions and 0.13 lb is package weight. They do not describe the exposed length of T6H or another individual bit.
How do I choose the right T6 or T7 bit for an electronics screw?
Read the exact Torx size, choose the matching bit and secure its 1/4-inch hex shank in the appropriate driver. Apply steady force and avoid excessive torque; the adjacent T-number is not a remedy for a worn recess.
What should I do if a bit or socket cracks or breaks?
Stop using the damaged piece and contact Lexivon with the model, issue description and clear photos. A break alone does not establish a covered defect; Lexivon assesses warranty eligibility.
Should my holder include T35 between T30 and T40?
T35 is not in the published thirteen-size inventory. Check the listed markings, including T27, T30 and T40; report an absent listed bit rather than assuming every number up to T40 should be present.
Can I keep using a rounded T6H while servicing a small ratchet?
Stop using the rounded T6H and check the screw's exact Torx profile and condition. Do not reshape the damaged tip or increase torque to finish servicing the small ratchet; use a suitable replacement.
Can I use these bits for prying, scraping or as punches?
No. Prying, scraping and punch use can break a bit and cause injury. Use these hex-shank bits only with a suitable drive tool for matching fasteners.
Does the warranty cover normal wear or modification?
No. Coverage excludes normal wear, misuse, modification and damage from non-original parts. Commercial use is limited to 12 months without extension; industrial use is excluded. Torque-wrench recalibration is also excluded.
Manuals & downloads
Download the documents for LX-301. Browse all manuals
